Brand: BOCH
Applicable Industry: Manufacturing Plant, Construction Works, Energy &Amp; Mining
Performance Features:
- The process design of the tonne bag packing system for alumina plant is compact and efficient. Alumina departs from the storage bin and smoothly enters the buffer bin above the tonne bagging machine through the air inclined chute, and the whole conveying process is stable and smooth, which reduces the risk of material blockage and retention.
- Salient Alumina Ton Bag Packaging Machine shows a high level of automation, which greatly reduces manual labour intensity and improves packaging efficiency. The use of microcomputer scale ensures accurate measurement, and the packaging accuracy can reach ±0.5%, effectively guaranteeing the consistency of the weight of each bag of alumina.
- The packaging capacity is outstanding, with an efficient packaging speed of not less than 40 bags per hour, which can meet the demands of mass production and bring significant capacity improvement for the enterprise.
- The equipment is stable and reliable, with very few breakdowns over long periods of continuous operation, reducing maintenance costs and the possibility of production interruptions.
- The advanced dust removal design is one of the system's major advantages, effectively controlling the flying of dust, significantly improving the working environment, safeguarding the health of the operators, and also meeting the requirements of environmental protection.
- The weighing system's full-board digital adjustment and parameter setting functions are easy to operate and highly sensitive, enabling quick response and adjustment of parameters to adapt to the needs of packaging of different specifications.
Main technical parameters:
- Packing accuracy: controlled within ±0.5%, ensuring the weight deviation of each bag of aluminium oxide is extremely small.
- Packing capacity: Packing speed of at least 40 bags per hour to meet the requirements of efficient production.
- The measuring range and resolution of the microcomputer scale are flexibly configured according to different packing specifications.
- The conveying speed, conveying length and carrying capacity of chain conveyor are customised according to the actual production site and transport requirements.
Main application fields:
- Widely used in large-scale alumina production enterprises to provide reliable support for the packaging and transport of their finished products.
- It is suitable for the trading of alumina to ensure accurate packaging and metering of products during sales and transport.
- In the field of alumina warehousing, it can efficiently complete the inbound packaging and outbound shipment of goods.
Important Tips:
- When installing the tonnage bag packaging system for alumina plant, choose a solid and level installation site and operate in strict accordance with the installation specifications. Ensure that the connection between the equipment is tight and solid to avoid loosening and leakage.
- Before installation, carefully check the integrity and quality of all equipment and components, and replace them promptly if they are damaged or defective. At the same time, make sure that the tools and auxiliary materials required for installation are complete and in good performance.
- Before operation, fully debug the system, check whether the electrical wiring is normal and the weighing system is calibrated accurately. Lubricate all moving parts to ensure their flexible operation.
- During operation, pay close attention to the running status of packaging machine and conveyor, if there is any abnormal sound, vibration or overheating phenomenon, it should be stopped immediately for inspection. Regularly check the sealing quality of the bags to ensure no leakage.
- Regularly clean up the residual material inside the packaging machine to prevent the accumulation from affecting the performance of the equipment. Check the chain plate and sprocket of chain conveyor for wear and replace the worn parts in time.
- Regularly calibrate and maintain the weighing system according to the requirements of the maintenance manual to ensure packaging accuracy. At the same time, check the operation effect of the dust removal equipment and clean or replace the filter parts in time.
- When stopping the machine for maintenance, be sure to cut off the power supply first and hang a warning sign at the power switch. In the process of overhauling, use appropriate tools and protective equipment, and comply with the safety operation regulations.
- Establish detailed equipment operation and maintenance records, including operation time, fault conditions, maintenance content, etc., in order to find problems in time and make reasonable maintenance plans.
