Mixing system for construction projects

High-efficiency uniform mixing: it can fully mix the measured sand, cement, water, additives and other raw materials to ensure the uniform distribution of concrete components.

Long-life parts: the selection of high-quality materials and advanced manufacturing technology makes the mixing system parts have a long service life.

Convenient installation characteristics: the mixing system adopts modular design concept, each component is pre-assembled and debugged in the factory, and can be quickly assembled and installed after transportation to the construction site. The installation process is simple and convenient, without the need for complex construction techniques and a large number of professional and technical personnel, which greatly shortens the installation cycle of the equipment.

Economic construction cost: Under the premise of ensuring the performance and quality of the equipment, the construction cost is effectively controlled through reasonable design and material selection.

Easy to operate and maintain: The operator interface is designed to be simple and intuitive, and the operator can master the operation process of the equipment after simple training.



Mixing capacity range: according to different models and configurations, the mixing capacity of the mixing system can range from 0.5 cubic meters to 10 cubic meters per batch. Small-scale mixing system is suitable for small-scale construction sites or prefabricated component factories for small batch production; medium-scale mixing system can meet the concrete supply of general construction projects; large-scale mixing system can provide large-scale concrete production capacity for large-scale infrastructure projects and commercial concrete mixing stations to meet the production requirements of different scales of projects.

Mixing power setting: The mixing power depends on the mixing capacity and mixing intensity requirements, generally between 15 - 300 kW. Higher mixing power ensures that the mixing system can maintain efficient and stable operation when mixing high-viscosity concrete or concrete with large aggregates, so that the raw materials can be fully mixed.

Mixing speed control: The mixing speed can be adjusted according to different mixing stages and concrete types, usually between 10 - 30 rpm. At the beginning of the mixing stage, a higher mixing speed can be used to mix the raw materials quickly; at the end of the mixing stage, the mixing speed can be lowered appropriately to minimize segregation of the concrete and improve the quality and stability of the concrete.



It is widely used in all kinds of construction projects, including residential buildings, commercial buildings, industrial buildings and so on. In the construction of residential buildings, it provides high-quality concrete for foundation pouring and main structure construction to ensure the structural safety and stable quality of housing buildings; in the construction of commercial buildings, it meets the concrete demand of large-scale buildings, such as shopping malls and office buildings, and ensures the smooth progress of the construction project; in the case of industrial buildings, it provides a reliable supply of concrete for the construction of factories, warehouses and other buildings. It is also suitable for infrastructure construction projects, such as highways, bridges, tunnels, water conservancy projects, etc. It provides a large amount of concrete that meets the quality requirements for these large-scale projects, and is an indispensable key equipment for infrastructure construction.



Before installation, the installation site should be investigated in detail to ensure that the site has a solid and level foundation, with enough load-bearing capacity and space to accommodate the mixing system and its supporting facilities. According to the site conditions and production requirements, reasonably plan the layout of the mixing system to ensure the smooth operation of material conveying, measuring, mixing and discharging.

Before the first operation, the mixing system should be fully cleaned internally, and the installation and function of the key parts such as mixing shaft, mixing blades, liner plate, metering device, transmission parts and so on should be checked to ensure that there is no damage or hidden trouble. Check and oil the lubrication system to ensure that the moving parts are well lubricated.

In the process of operation, establish a regular inspection system, focusing on checking the mixing effect of the mixing system, the wear and tear of the components, the accuracy of the measuring device, the operating status of the transmission system and so on. According to the running time and working condition of the equipment, arrange the maintenance plan reasonably, such as replacing the mixing blades, liners and other wearing parts regularly, calibrating the measuring device, checking the lubrication of the transmission parts and the degree of connection fastening, etc., to ensure that the equipment is always in a good running condition.

Long-term suspension or seasonal suspension of the equipment, before the suspension of the mixing system should be cleaned up the concrete, the equipment thoroughly clean the interior, to prevent the concrete residue caking affect the next use. Carry out a comprehensive inspection and maintenance of the various parts of the equipment, do a good job of anti-rust, anti-corrosion treatment, and keep the wearing parts properly.
