Performance characteristics:
- Large capacity and high degree of automation
Warehouse capacity, high degree of mechanical automation, management tends to be scientific, rationalization, network, can effectively reduce operating costs. Cement silo has large capacity and wide adaptability, with a single silo capacity of 5000 - 50,000 tons, which can meet the storage requirements of different industries and materials. At the same time, the level of automation of feeding and discharging is high, and the PLC system can be used to realize the automatic control with analog screen display, which improves the production efficiency and storage management level.
- Good sealing
Adopting special equipment for bending and nibbling of rolled silo, the sealing performance is very good. The cement silo adopts special equipment for bending and nibbling, which can ensure the quality of any part of the silo, and the sealing performance is especially good. If the cement is stored, it can make the cement not damp and not slate; if the grain is stored it can meet the requirements of insecticide and fumigation process.
- Long service life
The material of the silo body can be selected according to the requirements of the stored materials for corrosion resistance and grinding strength, and the normal service life can reach 30-40 years. 150 tons of cement silo outer coin adopts the material with particularly strong anti-corrosion performance, which makes it more corrosion-resistant performance. The material of the silo body can be reasonably selected according to the stored materials, ensuring the normal service life of 30 - 40 years.
- Good storage effect
When the material is located in the middle of the silo, the silo wall has a tight air separation, the inside is basically a vacuum sealing, the effect is far more than the traditional silo. When the material is located in the middle of the
Steel Plate Warehouse, due to the steel plate warehouse wall has a tight air separation, so basically inside the vacuum sealing storage. This sealing of the traditional steel plate warehouse can not be compared, its effect than brick, stone, concrete structure as a storehouse body is too good.
Main technical parameters:
- Different parameters for different models
Take 80 tons of cement silo as an example, steel plate material for Q235, tank diameter 3m, tank height 10.5m, cone height 2.5m, the height of the discharge port from the ground 1.5m, the distance between the legs 2100mm, the overall weight of 5000kg, matching mixer JS750, matching screw conveyor LSY219. other models such as 30T - 300T and so on also have the corresponding parameters.
30 tons of cement silo: tank diameter 2.5m, tank height 6.0m, the height of the vertebrae can refer to the ratio of other models, the height of the discharge port from the ground and the distance of the legs can be reasonably set according to the overall structure, the overall weight can be estimated as a certain value, matching mixer and screw conveyor according to the actual situation.
50 tons of cement silo: tank diameter 3m, tank height 7.5m, the height of the vertebrae can refer to the ratio of other models, the height of the discharge port from the ground and the distance of the legs can be reasonably set according to the overall structure, the overall weight can be estimated as a certain value, matching mixer and screw conveyor configured according to the actual situation.
300 tons of cement silo: tank diameter 4.5m, tank height 24.6m, the height of the vertebrae can refer to the ratio of other models, the height of the discharge port from the ground and the distance of the legs can be reasonably set according to the overall structure, the overall weight can be estimated as a certain value, matching mixer and screw conveyor configured according to the actual situation.
Main application areas:
- Concrete mixing plant
It is generally used in the bulk cement storage of concrete mixing plant, which is a part of the mixing plant and suitable for storing various bulk materials such as grain, cement, fly ash, etc. Cement silo plays an important role in concrete mixing plant, its airtight performance is good, the use of special equipment for rolling silo bending, biting, to ensure the quality of the silo and sealing, can make the stored materials do not get damp, do not slate, to meet the requirements of insecticidal, fumigation process.
- Construction, water conservancy and other fields
Used in construction, water conservancy and other projects for bulk cement storage silo, can be used with the screw conveyor pump to transport materials to various locations. Cement silo is a kind of closed tank for storing bulk materials, which is widely used in construction, water conservancy and other fields. Its components such as pressure safety valve, dust collector, arch-breaking device, material level meter and so on have important roles.
- Food, chemical, coal and other fields
It has been extended to many fields such as food, chemical, coal and so on, and is used to store all kinds of bulk materials. The development of cement silo has a history of more than 100 years, with the progress of science and technology, its use continues to expand. In the food, chemical, coal and other fields, cement silo can be used to store a variety of bulk materials.
Important Tips:
- Check whether the line is smooth before use. This step is crucial to ensure that the cement silo will not fail due to wiring problems during operation. If the line is not smooth, it may lead to the equipment of the cement silo not working properly, affecting the storage and delivery of cement.
- Turn on the vibration for 2 - 3 minutes before and after the cement tanker is filled with ash. This can effectively prevent the cement from clogging and caking during transportation between the tanker and the cement silo. Vibration loosens the cement for smooth injection and discharge.
- Take care to prevent damage to the cement tanker alarm and dust handler. Alarms and dust handlers play an important safety and environmental role in the use of cement silos. Once damaged, they may lead to safety accidents or environmental pollution. Therefore, extra care should be taken during operation to avoid damage to these devices.
- The height of cement silo legs needs to be reasonably designed to avoid too high affecting the safety factor and inspection, cleaning and maintenance. Too high a height of the legs will reduce the stability of the cement silo and increase the safety risk. At the same time, it will also bring difficulties in inspection, cleaning and maintenance. Therefore, when designing and installing the cement silo, the height of the legs should be reasonably determined according to the actual situation.
