Brand: BOCH
Applicable Industry: Energy &Amp; Mining, Other
Performance Features:
-Modular and efficient design:
China XCJ Series Planetary Differential Gearboxes the modular design concept is adopted to make the gearbox structure more compact. Each module is carefully optimized, which not only saves installation space, but also improves production efficiency and effectively shortens delivery time.
-Excellent Gear Shaping Technology: Unique gear shaping technology is applied to precisely optimize the gear tooth profile. By improving the gear meshing performance, it makes the tooth surface contact more uniform and effectively reduces the meshing shock and vibration, thus realizing a substantial increase in the smoothness of transmission and a significant reduction in operating noise.
High-quality hardened gear design: The gears are manufactured with hardened gear design in strict compliance with high international standards such as ISO, AGMA and DIN. The hardened gear face material gives the gears higher strength and wear resistance, which can withstand the huge loads and frequent shocks generated by the bridge grab unloader in loading and unloading operations, and ensures the gearboxes to operate stably and reliably under the harsh working conditions.
-Flexible Lubrication Configurations: A variety of lubrication configurations are available, which can be selected according to different working conditions. Whether it is high temperature, high humidity port environment, or heavy load, long time continuous operation, can ensure that gears and bearings inside the gearbox get good lubrication and cooling.
Main technical parameters:
-Accurate adaptation of speed ratio range: the speed ratio range is between 11.2 - 50, which can be precisely adjusted according to the specific operational requirements of the bridge grab ship unloader.
-Reasonable center distance between the two output shafts: the center distance between the two output shafts is 800 - 2,800 (mm), which is designed to adapt to the structural layout of different specifications of bridge grab ship unloaders.
-Powerful maximum loading and unloading capacity: the maximum loading and unloading capacity is up to 5,000 t/h, which is a powerful loading and unloading capacity to meet the rapid loading and unloading requirements of large harbor ships.
Main application areas:
It is mainly applied to bridge grab ship unloader, which is the key port equipment. In harbor cargo handling operation, bridge grab unloader undertakes the important task of unloading bulk cargo from ship to shore. This series of
Lifting Gearboxes, as its core component, realizes efficient and stable cargo grabbing and unloading by converting the input motion of the motor into the precise motion combination of the four reels and accurately controlling the actions of the grab such as lifting, opening and closing, and walking. Whether it is the loading and unloading of bulk materials such as coal, ore, grain, etc., or in the operation of port terminals of different scales,
Gearboxes for harbour cranes in bulk terminals plays an indispensable role in guaranteeing the smooth operation of port logistics, and it is one of the indispensable key equipments in modern port loading and unloading operation.
Important Tips:
-Precise matching of selection: When selecting this series of gearboxes, users should precisely calculate the required speed ratio, center distance and other technical parameters according to the specific parameters of the bridge grab ship unloader, such as grab capacity, lifting height, operating speed, working frequency and the operating environment of the port, etc., so as to ensure that the selected gearboxes are perfectly matched with the equipment.
-Installation and commissioning specifications: the installation of the gear box must be carried out in strict accordance with the product installation manual to ensure that the installation position is accurate and the connecting parts are firm and reliable, paying special attention to the coaxiality of the output shaft and the reel and the precision of the connection, to prevent vibration, noise increase and damage to the parts caused by the installation error.
-Regularization of maintenance: establish a regular maintenance system, and reasonably determine the maintenance cycle according to the working intensity of the gearbox and the environmental conditions of the port. Regularly check the oil quality and oil quantity of lubricating oil, replace the deteriorated or polluted lubricating oil in time to ensure that the gears and bearings are well lubricated and cooled. Regularly check the meshing of gears, the sealing effect of seals and the tightness of each connecting part, so as to discover and deal with potential problems in time.
