Performance features:
-Structural optimization with the help of finite element: With the help of the powerful tool of finite element analysis, the structure of key parts is optimized in depth. By simulating the force and deformation of the parts under various working conditions, the shape, size and material distribution of the parts are precisely adjusted, making the key parts more compact under the premise of ensuring sufficient strength and stiffness.
-Excellent tooth profile trimming technology: Using advanced optimized tooth profile trimming and tooth direction trimming technology, the tooth surface of the gear is finely trimmed. This kind of trimming can effectively improve the contact state of gears in the process of meshing, make the load distribution on the tooth surface more uniform, and thus significantly improve the bearing capacity of gears.
High-quality hardened gear design: The gears are designed with hardened gears and manufactured in strict compliance with high international standards such as ISO, AGMA and DIN. The hardened gear face material gives the gears higher hardness and wear resistance, which can withstand greater loads and impacts and ensure the stable and reliable operation of the gearboxes under severe working conditions.
Main technical parameters:
-Accurate setting of speed ratio range: the speed ratio range is 49.26 and 57.57, these two specific speed ratio values are carefully designed and verified by practical application, which can accurately match the speed requirements of anchor diggers in different working stages.
-Powerful rated power output: rated power ≥ 315 kW, this high power output capability enables the gearbox to provide sufficient power support for the anchor digger.
Main application areas:
It is mainly applied to the key mining equipment of
Ore mining transportation. In the mining process of coal mines, metal mines and other types of mines, the anchor digging machine undertakes the important task of excavating the roadway and carrying out anchor support at the same time. This series of gearboxes, as the core transmission components of anchor digging machine, provides reliable
Power transmission and accurate speed control to ensure that the anchor digging machine can operate stably in the complex and harsh underground environment, and efficiently complete the development and support work of the roadway to improve the safety and productivity of
Mining ore transportation, which is indispensable for ensuring the normal production and operation of the mines.
Important Tips:
-Selection and adaptation is crucial: users in the selection of this series of gear box, be sure to combine the specific model of anchor digging machine, working parameters and geological conditions of the mine and other factors for comprehensive consideration.
-Installation and commissioning strict norms: in the installation process of the gear box, must be strictly in accordance with the product installation manual and relevant standards for operation, to ensure that the installation position is accurate, the connecting parts are firm and reliable, and attention should be paid to ensure that the coaxiality and clearance between the gear box and the motor, the anchor digging machine and other parts of the working mechanism to meet the requirements.
-Maintenance of regular fine: establish a regular maintenance system, according to the working intensity of the gear box and the harshness of the underground working environment, to reasonably determine the maintenance cycle. Regularly check the oil quality and oil quantity of the lubricant, replace the deteriorated or contaminated lubricant in time, and ensure that the gears and bearings and other key components are well lubricated.
