Performance Features:
-Advanced platform and modularity advantage: Relying on the advanced platform system for research and development, it adopts the modularization design concept. This design makes the various parts of the
Mining Equipment Gearboxes highly interchangeable, which not only improves the assembly efficiency and reduces the production cost during the production process, but also can quickly replace the damaged parts during the maintenance and repair of the equipment, reducing the downtime and guaranteeing the continuity of the coal mine production.
-Compact structure and quick delivery: The modular design also makes the JS series scraper gearboxes compact, which can be easily installed and laid out in the limited underground space of coal mines, saving valuable space resources.
Excellent Gear Shaping Technology: Unique gear shaping technology is used to precisely optimize the tooth profile of gears. This technology improves the contact state of the gears in the meshing process, makes the force on the tooth surface more uniform, and effectively reduces the meshing shock and vibration.
-Reliable sealing solutions: Equipped with a variety of sealing forms and designed with special sealing structures to effectively cope with the harsh working environment of underground coal mines.
-Efficient large inclination design: The unique large inclination design enables the scraper conveyor, transfer machine and other host equipment to work normally at a larger inclination angle, improving the coal conveying efficiency and mining range.
Main technical parameters:
-Speed ratio range: the speed ratio is between 3.5 - 40, which can be flexibly adjusted according to the different working conditions and operation requirements of scraper and transfer machine.
-Power range: the power covers 40 - 1,600 (kW), which can meet the power requirements of scrapers and transfer machines in different sizes of coal mines.
Main application fields:
Mainly used in
Offer Conveyor Gearboxes and transfer machine and other key equipment in coal mine. In the scraper conveyor, as the core transmission component, it is responsible for driving the scraper chain, realizing the continuous transportation of coal from the coal mining face to the downstream channel, which is an important part of the coal mining process. In the scraper transfer machine, it also plays a key role in efficiently transferring the coal carried by the scraper conveyor to the subsequent transportation equipment such as the tape conveyor, guaranteeing the smoothness and continuity of coal transportation, improving the efficiency and reliability of the whole
Ore Material Transportation system, and is an indispensable equipment component for the safe and efficient production of coal mine.
Important Tips:
-Precision of selection: When choosing JS series scraper gearboxes, coal mining enterprises must precisely calculate the required technical parameters such as speed ratio and power according to the actual working conditions of the scraper and the transfer machine, including the conveying length, inclination angle, coal production, working environment and other factors.
-Installation and debugging professionalism: During the installation of the gear box, it must be operated in strict accordance with the installation manual of the product, and be installed and debugged by professional technicians. Ensure that the gear box installation position is accurate, the connection with the motor, scraper chain and other components is firm and reliable, pay attention to adjusting the coaxiality and clearance and other parameters, to prevent vibration, noise increase and premature wear of parts and other problems caused by improper installation.
-Regularization and standardization of maintenance: establish a strict regular maintenance system, and reasonably determine the maintenance cycle according to the working intensity of the gear box and the underground environmental conditions. Regularly check the oil quality and oil quantity of lubricating oil, replace the deteriorated or insufficient lubricating oil in time to ensure the good lubrication of gears and bearings.
