Performance Features:
-With good speed regulation performance, it can quickly and smoothly adjust the rotational speed and rolling speed of the mill according to different rolling process requirements, so as to improve the production efficiency and product diversity.
-Optimised lubrication and cooling system can effectively reduce the working temperature of gears and bearings, reduce wear and prolong service life. At the same time, the system can also ensure that the gearbox still maintains stable performance under high loads and long hours of continuous work.
-
Metallurgical Equipment Gearboxes adopts advanced sealing technology to effectively prevent lubricant leakage and the intrusion of external impurities, which ensures clean and good lubrication environment inside the gearbox and reduces the incidence of malfunction.
-Compact structural design makes the gearbox easier to install and maintain, saving space and time costs. At the same time, its modular design concept facilitates the replacement and upgrading of components.
-With good shock and vibration resistance, it can adapt to the frequent load changes and shocks of the rolling mill during starting, braking and rolling, ensuring the reliability and stability of the equipment.
Main technical parameters:
-Torque range: up to 1,200 kN.m, to meet the torque requirements of mills of different specifications.
-Speed ratio range: 1-120, providing a wide range of speed regulation options.
-Output shaft centre distance: up to 1,100 mm, adapting to a wide range of installation dimensions.
-Installed power range: 132-2,250 (kW), providing sufficient power support for rolling mills.
Main areas of application:
-The steel industry for the rolling production of various steel products, such as plates, wires and profiles.
-Non-ferrous metal processing field, such as copper, aluminium and other metal rolling process.
-Metal products industry, involved in the rolling process of metal sheet and strip.
Important Notice:
-When installing MRG series rolling mill gearboxes, make sure the installation foundation is firm and level, and follow the installation manual strictly to ensure the installation accuracy.
-Prior to operation, conduct a thorough inspection of the gearbox, including the connection of each component, the level and quality of lubricating oil, etc., to ensure that everything is normal.
-During the operation of the mill, pay close attention to the temperature, pressure, sound and other parameters of the gear box, and if there is any abnormality, it should be shut down in time for troubleshooting.
-Maintain the gear box according to the specified cycle, including replacing the lubricating oil, checking the wear of gears and bearings, etc.
-When the gear box is faulty, it should be shut down and cut off the power supply first, and be repaired by professional technicians, do not dismantle it privately.
-Regularly check and replace the seals of the gear box to prevent the lubricant from leaking and external impurities from entering.
-Establish a perfect equipment operation and maintenance file to record each maintenance and troubleshooting situation for subsequent reference and analysis.
-When restarting after a long period of shutdown, the gearbox should be thoroughly inspected and warmed up to ensure its normal operation.
