Brand: BOCH
Applicable Industry: Manufacturing Plant, Construction Works, Energy &Amp; Mining
Performance characteristics:
- MHS series
Chemical mixing gearboxes are based on a standard platform, combining modularity with special designs tailored for chemical and environmental protection conditions. This combination ensures the universality and stability of the product while taking into full consideration the complex working conditions of chemical mixing tank equipment and the strict requirements for high reliability, thus maximising the economic applicability.
- Optimised tooth profile trimming and tooth direction trimming technology is a significant advantage of this series of gearboxes. Through precise calculations and fine adjustments, the load distribution on the tooth flanks reaches a more uniform state, which greatly avoids the occurrence of localised overload conditions. This not only significantly improves the gear's load carrying capacity and ensures stability during long-term heavy-duty operation, but also effectively extends the gear's service life and reduces maintenance costs.
- Adopting hardened gear design, the gears strictly comply with high international standards such as ISO, AGMA and DIN. During the manufacturing process, high-quality materials are selected and advanced heat treatment and precision machining processes are applied to provide the gear surface with ultra-high hardness and excellent wear resistance. Even in the chemical industry facing complex and changing harsh environments, the gears can still show excellent performance, effectively resisting wear, corrosion and fatigue and other damages.
- A wide variety of sealing forms are available, with a unique sealing structure. This design is able to cope with the extreme challenges of high temperatures, high pressures and highly corrosive media that may be encountered during chemical mixing processes, significantly reducing the risk of leakage. This not only ensures a safe and clean working environment, but also reduces material leakage and potential damage to the equipment, ensuring a stable and reliable production process.
- Equipped with a wide range of optional accessories, users can flexibly choose accessories such as cooling units, lubrication systems, monitoring instruments, etc., according to specific application scenarios and unique process requirements. These accessories not only enhance the function and performance of the gearbox, but also further improve the cost-effectiveness of the product, which fully meets the diversified and individual needs of different users.
Main technical parameters:
- With a wide torque range from 137 to 340 (kN.m), the gearboxes can fully meet the needs of various large-scale chemical mixing equipments for strong torque. Whether it is a mixing tank handling high viscosity materials or a reactor requiring fast mixing, the ideal power configuration can be found within this torque range, ensuring efficient and stable mixing processes.
- The range of speed ratios from 22.4 to 450 provides the user with a wide scope for speed adjustment. The output speed can be precisely adjusted according to the specific chemical mixing process requirements and material characteristics to achieve the best mixing effect and reaction process control, meeting the precise requirements for equipment performance in different chemical production processes.
Main application areas:
- In the application of seed separation tank, MHS series gearboxes can provide stable and precise stirring power for crystal growth and separation process. The MHS series gearboxes can adapt to the characteristics of the materials and process requirements in the seed separation tank to ensure the uniform distribution of crystals and a good growth environment, which is widely used in the aluminium industry and other fields of production processes.
- In the high-pressure dissolution tank, facing the high temperature, high pressure and strong corrosive material environment, the gearbox can provide strong and reliable stirring power to promote the full dissolution and reaction of the material, which plays a key role in non-ferrous metal smelting and other industries.
- The processing of pre-desilication tank requires fine mixing control, this series of gearboxes can meet this demand, ensure the uniform mixing and reaction of materials in the pre-desilication process, improve the production efficiency and product quality, which plays an important role in the chemical and metallurgical industries.
- In the masterbatch tank, the gearbox can stir the masterbatch stably, maintain the uniformity and stability of its composition, and provide a reliable material base for the subsequent production process, which is commonly used in chemical and pharmaceutical industries.
- As the core equipment in chemical production, MHS series gearboxes can provide precise stirring speed and strong torque to adapt to the needs of various chemical reactions to ensure the full implementation of the reaction and product consistency, which is widely used in fine chemicals, petrochemicals, and many other fields.
- For all kinds of chemical mixing operations, whether it is mixing, dispersing, emulsifying or chemical reactions, this series of gearboxes can provide efficient, stable and reliable mixing power support for all aspects of chemical production by virtue of its excellent performance and adaptability.
Important Notice:
- Installation to ensure that the site is clean, solid foundation, according to the drawing instructions.
- Make sure the tools and materials are complete and qualified before installation.
- Before operation, fill up the specified lubricant, check the lubrication and electrical system.
- Pay attention to the status during operation, abnormal shutdown and check the seal.
- Regular maintenance and cleaning, checking wear and tear and replacing parts and lubricants.
- Regular inspection and debugging according to the requirements, maintained by professional personnel.
- Stopping for maintenance, disconnecting the power first and locking the tag, correct operation to prevent damage.
- Enhance the protection of harsh environments, and use genuine parts for maintenance and debugging.
- Establish a file, analysis and summary to identify problems and improvements.
