Brand: BOCH
Applicable Industry: Manufacturing Plant, Construction Works, Energy &Amp; Mining
Performance characteristics:
- The MHP series pump gearboxes are based on a standard platform that combines modular design with special design for slurry conveying conditions. This combination ensures the universality and stability of the product, while the special design meets the complex and highly reliable requirements of the mining and beneficiation industry, thus maximising the economic applicability.
- One of the core advantages is the optimised tooth profile and tooth direction trimming technology. Through precise calculations and adjustments, the load distribution on the tooth surface is more uniform, effectively avoiding the occurrence of local overload phenomenon. This not only significantly improves the bearing capacity of the gears, but also extends the service life of the gears and guarantees the stability and reliability of the gearbox in long-term high-load operation.
- The hardened gear design strictly follows the requirements of high international standards such as ISO, AGMA and DIN. During the manufacturing process, high quality materials are selected and advanced heat treatment and processing techniques are applied to provide the gear surface with extremely high hardness and wear resistance. Even under severe working conditions, they can maintain good working performance and effectively resist wear and fatigue damage.
- Provides a variety of sealing forms and has a unique sealing structure. This design can effectively cope with the challenges of high pressure, high abrasion and corrosive media that may occur during slurry conveying, greatly reducing the risk of leakage, ensuring a clean and safe working environment, and reducing material loss and damage to equipment.
- Equipped with a wide range of accessory options, users can flexibly select accessories such as cooling devices, lubrication systems, protective housings, etc. according to specific application scenarios and process requirements. These accessories not only enhance the function and performance of the gearbox, but also further improve the cost-effectiveness of the product to meet the individual needs of different users.
Main technical parameters:
- The wide range of torque, from 4 to 136 (kN.m), can adapt to the diversified torque requirements of different types and specifications of pump equipment. Whether it is a small light-duty pump or a large heavy-duty pump, you can find the right configuration within this torque range to ensure the accuracy and stability of Power transmission .
- The range of speed ratios from 1.25 to 5.6 provides users with a moderate choice of speed regulation. The output speed can be precisely adjusted according to the specific pump equipment working requirements and process characteristics to achieve the best pumping effect and energy utilisation efficiency, and to meet the specific requirements of different application scenarios on equipment performance.
Main application areas:
- In slurry pump applications, MHP series gearboxes can provide strong and stable power support for handling slurries containing solid particles. Adapt to the high abrasion and corrosive environment of slurry, ensure the efficient conveying of slurry, widely used in mining, metallurgy and other industries of tailings treatment and slurry conveying link.
- For water pumps, whether it is urban water supply, industrial water or agricultural irrigation and other fields, the gear box can precisely control the speed and torque of the pump, to ensure the stable transmission of water and pressure regulation, to meet different water needs.
- Axial flow pumps and irrigation pumps play an important role in water conservancy projects, sewage treatment and large-scale cooling systems, for which MHP series gearboxes provide reliable power transmission to ensure efficient operation and flow control of the pumps, and realise rational allocation and recycling of water resources.
- Vacuum pumps are indispensable for vacuum processes in chemical, electronic and pharmaceutical industries. This series of gearboxes can adapt to the high-speed and high-precision requirements of vacuum pumps, providing a stable drive to ensure the normal operation of the vacuum system and process quality.
- Reciprocating pumps are commonly used in high-pressure, low-flow conveying applications in the petroleum, chemical and food industries, etc. The MHP series gearboxes are able to match the operating characteristics of reciprocating pumps, provide reliable power conversion and control, and ensure the accurate conveying of materials and process stability.
Important Note:
- Make sure the foundation is level and solid for installation, and operate according to the instructions to ensure accuracy.
- Inspect the exterior and interior thoroughly before installation and make sure the tools and materials are complete.
- Before operation, fill the lubricant, check the lubrication and electrical system.
- Pay attention to the status during operation and deal with abnormal shutdown.
- Regularly check the sealing, clean to keep heat dissipation, according to the requirements of maintenance.
- Disconnect the power before stopping for maintenance and hang up the licence to brake, and operate correctly to prevent damage.
- Enhance the protection in harsh environment, use genuine parts for maintenance and debugging.
- Establishment of archives to provide a basis for management and decision-making.
