Brand: BOCH
Applicable Industry: Construction Works, Energy &Amp; Mining, Manufacturing Plant
Performance characteristics:
-Carefully built based on standard platform, it is a perfect combination of modularization and special design, which ensures excellent performance and at the same time more economic applicability. This unique combination not only makes full use of the mature technology and cost advantages of the standard module, but also allows precise customization for the special working conditions and structural requirements of the mining spiral vertical mill.
-Adoption of multi-floating load equalizing mechanism design significantly improves the load carrying capacity. It is able to operate stably under complex and heavy-duty working conditions in mines, and can easily cope with all kinds of high-intensity operational requirements.
-The torque range is reasonably distributed, which not only meets the power demand of the tower mill, but also avoids the waste of resources caused by over-configuration, realizing the balance between economy and practicality.
-Equipped with maintenance-free sealing structure, which greatly improves the maintainability of the product. It reduces the number of failures and repairs caused by sealing problems, lowering maintenance costs and downtime.
-The unique gear shaping technology plays a key role in significantly improving the gear meshing performance. It makes the transmission process more stable and smooth, greatly reduces the operation noise, and creates a quieter and more comfortable conditions for the working environment.
Main technical parameters:
-The torque range is 85-4,300 (kN.m), which can provide powerful and stable torque output for tower mills and adapt to fine grinding operations of different sizes and loads.
-The range of speed ratios from 22-70 provides moderate adjustment of the tower mill operating speed, which can be precisely adjusted according to the material characteristics and process requirements.
-The installed power ranges from 132-2,250 (kW), which widely covers the power requirements of tower mills and provides sufficient and stable power support for the equipment.
Main application areas:
-As a supporting equipment, it works with the tower mill to provide reliable Power transmission and precise speed control. In the fine grinding of non-ferrous metals, it can process the ore finely and improve the recovery rate and grade of the metal.
-In the beneficiation process of gold ore, it helps to realize the full dissociation and refinement of gold particles, and improve the beneficiation efficiency and purity of gold.
-For non-metallic minerals, such as quartz, feldspar, etc., it can realize high-quality fine grinding and meet the requirements of various industrial applications for the fineness and purity of non-metallic minerals.
Important Tips:
-When installing the MPT Series Tower Mill Gearbox, it is important to ensure that the mounting base is firm and level, and that the installation manual is strictly followed to ensure the precision and alignment requirements for the connection between the gearbox and the tower mill.
-Before installation, fully inspect the appearance of the gearbox, internal parts and supporting accessories to ensure that there are no damages, defects or omissions, and make sure that the tools and equipment required for installation are complete and in good condition.
-Before operation, fill the appropriate amount of lubricating oil according to the regulations, and carefully check the working condition of the lubrication system to ensure that the lubrication is sufficient and effective.
-During operation, pay close attention to the oil temperature, oil pressure, sound, vibration and sealing condition of the gearbox, once abnormalities are found, it should be immediately shut down for inspection and timely troubleshooting.
-Regularly check the integrity and effectiveness of the sealing structure, and replace it in time if it is damaged or aged to prevent lubricant leakage and entry of external impurities.
-Regularly maintain the gearbox according to the requirements of the maintenance manual, including cleaning, checking the wear and tear of gears and bearings, replacing lubricating oil and wearing parts.
-When stopping the machine for maintenance, be sure to cut off the power supply first and wait for the gearbox to stop running completely to ensure the safety of the operators.
-When used in harsh environments such as mines, the protective measures for the gearbox should be strengthened, such as increasing the protective casing, and cleaning up dust and debris on a regular basis.
-When repairing and replacing parts of the gear box, the original genuine parts should be used and operated by professional technicians to ensure its performance and reliability.
-Establish detailed equipment operation and maintenance files to record each inspection, maintenance, repair and replacement of parts and components, so as to discover potential problems and formulate reasonable maintenance plans in time.
